DJI NAZA M V2 Multirotor Autopilot Controller set with GPS

Description

DJI NAZA M V2 Multirotor Autopilot Controller set with GPS

the DJI NAZA-M V2 Autopilot Controller Set, a professional-grade flight controller system engineered for precision, stability, and ease of use. Featuring advanced flight stabilization, integrated GPS module, and intelligent orientation control, this system is ideal for serious aerial enthusiasts, FPV pilots, and professional UAV applications.

The NAZA-M V2 supports a wide range of multirotor configurations including quadcopters, hexacopters, and octocopters. Whether you’re capturing cinematic footage or conducting aerial inspections, the system ensures reliable position hold, auto return-to-home (RTH), and intelligent flight control, all packed in a compact, easy-to-install form factor.

Key Features:

• Supports Multiple Multirotor Types – Quadcopters, hexacopters, and octocopters
• High-Precision GPS Module Included – Enables accurate position hold and return-to-home (RTH)
• Intelligent Orientation Control (IOC) – Easy front/back orientation regardless of the aircraft’s direction
• Return-to-Home & Failsafe Function – Automatically returns the drone to the home point on signal loss
• Advanced Stability Algorithms – Smooth, responsive flight even in windy conditions
• Built-in Gimbal Stabilization – Supports 2-axis gimbal control for camera stabilization
• Compact All-in-One Design – Easy to install and configure
• Assistant Software via USB – Simple PC interface for tuning and firmware updates
• Flight Mode Switch Support – Manual, Atti, and GPS mode switchable via remote control
• LED Module with USB Port – For real-time status indication and configuration

Specifications:

• Controller Model: DJI NAZA-M V2
• Supported Frames: Quad (X or +), Hexa (IY, Y6), Octo (IY, V)
• GPS Module: External GPS/Compass unit included
• Input Voltage: 4.8V – 7.2V (BEC power supply)
• MC Dimensions: 45.5mm × 31.5mm × 18.5mm
• GPS Dimensions: Diameter 50mm; Height 10mm
• Weight:
• Main Controller: ~25g
• GPS Module: ~21.3g
• Operating Temperature: -10°C to +50°C
• Assistant Software: DJI NAZA Assistant (Windows compatible)

Applications:

• Aerial photography & videography drones
• DIY multirotor builds
• Surveying, mapping, and inspection drones
• FPV racing and hobbyist UAV projects
