PROXIMITY SWITCH NPN LJ 12A3-4-Z/BX PSNPN

Description

The Network Cable Tester is a compact and reliable tool designed to test the integrity and connectivity of various cables including LAN, telephone, and USB. Ideal for technicians, IT professionals, and network installers, this tester quickly identifies wiring faults such as open circuits, short circuits, cross connections, and miswiring. With its simple design and clear LED indicators, it ensures accurate testing and easy operation.

Features:

Output Type: NPN-NO Red LED checks the state of the proximity sensor High repeated positioning accuracy High switching frequency Wide voltage range Antivibration, dust, water and oil prevention

PROXIMITY SWITCH NPN LJ 12A3-4-Z/BX

Reverse power protection, short circuit protection, directly connecting with PLC Can replace small switches and limit switches

Specifications:

Model: LJ12A3-4-Z/BX  Type: Inductive Proximity Sensor Output Type: NPN, Normally Open (NO)

Sensing Distance: 4mm Power Supply Voltage: DC 6–36V

Output Current: 300mA max Detection Object: Metal (best for iron/steel)

Response Frequency: 500Hz  Housing Material: Nickel-plated brass

Cable Length: ~1.2m (3-wire)  Operating Temperature: -25°C to +70°C
