2 Pin SPST ON/OFF Red Rocker Switch (Pack of 5) RS14

Description

2 Pin SPST ON/OFF Red Rocker Switch (Pack of 5) RS14

This Rocker switch works on SPST (Single Pole Single Throw) mode. This switch is rated for a load of 6A 250V and 10A 125V. The contact resistance of the switch is ≤ 20 MΩ and the insulation resistance of the switch is ≥100MΩ. SPST Round Rocker switches have two positions which are ON and OFF. To make identification of the position of the button easy ON and OFF positions are clearly marked on the button as I and O respectively. Dimensions are L 2 cm x W 1.4 cm x H 2.0 cm

1. Voltage :- 250V AC
2. Current : 6Amp, 10A
3. Type: SPST
4. Contact Resistance: 20m ohm
5. Insulation Resistance: 100 M ohm
6. Size: 20.5 x 14 x 20mm
7. Color:- Red
