Description
The Infrared Obstacle Avoidance Tracking Sensor is a compact and reliable module designed for obstacle detection and line tracking applications in robotics and automation. It uses infrared light to detect objects and surfaces, making it ideal for smart robots, automated cars, and DIY electronics projects. With adjustable sensitivity and simple interface, it can be easily integrated with microcontrollers like Arduino, Raspberry Pi, and more.
Features:
IR Infrared Obstacle Avoidance Sensor Module can be widely used in robot obstacle avoidance, obstacle avoidance car, line count, and black and white line tracking and so on the module detects the distance 2 ~ 30cm, detection angle 35 ¡ã, the distance can detect potential is adjusted
The output port OUT sensor module can be directly connected to the microcontroller IO port, you can directly drive a 5V relay it has a pair of infrared transmitting and receiving tube, tube infrared emit a certain frequency, when detecting direction meet with obstacles (reflecting surface), reflected infrared receiving tube, after the comparator circuit processing, green indicator will light up, at the same time signal output interface to output digital signal (a low level signal).
Can be used for 3-5V DC power supply modules. It has red power indicator.
Specifications:
Operating Voltage: 3.3V – 5V DC
Detection Range: 2 cm – 30 cm (adjustable)
Output Type: Digital signal (HIGH/LOW)
Interface: 3-pin (VCC, GND, OUT)
Sensor Type: Infrared emitter and receiver
